REALISTIC CLOUD ILLUMINATION |
![]() |
|||||||||
We use hardware blending and read back to pre-compute multiple forward scattering and transmission of light through the cloud. | ![]() |
|||||||||
At runtime, we simulate anisotropic scattering toward the viewpoint by modulating shaded particle colors by a | ![]() |
|||||||||
phase function. Then we render the shaded and modulated particles as textured splats. | ![]() |
|||||||||
![]() |
![]() |
Multiple Forward Scattering
Clouds exhibit strong multiple light scattering dominated by scattering in the light direction.
|
|||
![]() |
![]() |
The top image shows the increased realism produced by our multiple forward scattering
approximation. The bottom image shows that clouds
shaded with only single scattering appear unrealistically dark. |
||
Anisotropic Scattering
Light scattering in clouds is more intense in directions toward and away from the light source.
|
![]() |
||
By modulating particle colors with ananisotropic phase function, clouds achieve the characteristic "glow" shown in the top
image. The bottom image shows the uniformity of clouds shaded with a purely isotropic scattering phase function.
|
![]() |
![]() |
|
IMPOSTORS
We use impostors to accelerate cloud rendering. An impostor replaces a cloud with a billboard textured with an image of the cloud
from a certain viewpoint.
|
|
![]() |
The image is updated only when translation of the viewpoint introduces enough error in the image to make it invalid.
Impostors allow the rendering of a cloud to be reused for many frames. By using impostors, we are able to
render cloudy scenes of hundreds of clouds and hundreds of thousands of particles at very high frame rates.
|
Impostor Splitting
We render aircraft passing through clouds by using "impostor splitting". The images to the right demonstrate this process,
progressing from bottom to top. First, we render the portion of the cloud that is farther from the viewpoint than the
airplane. Next, we render the airplane on top of the far portion. Finally, we render the portion of the cloud that is closer
to the viewpoint than the airplane.
|
![]() |
|||||
![]() |
![]() |
|||||
![]() |
![]() |
|||||
